Print Head

 4 x Epson I3200-E1 Print Heads

Technology

 Piezo Variable Dot (Greyscale)

Ink

 EPI2-2 Years Durability Eco-Solvent Ink

Color Config.

 K.C.M.Y.

Ink Supply System

 Bulk Ink System with Ink Cartridges

Ink Tank

 2000ml

Printing Width

 Max. 3200mm

Media Type

 Banner, Coated PP, Vinyl, PVC Film......

Roll Specification

 Diameter: Max. 300mm; Weight: 150kgs; Core Diameter: 3 inches or 2 inches

Dying System

 Three Heaters and Dual IR Dryers

Printing Speed

 Draft                               720x1200 dpi               107m2/h

 Production                      720x1200 dpi               81m2/h

 High-Res                        720x1800 dpi               61m2/h

 Photo                              720x1800 dpi               45m2/h

Data Interface

 External: Ethernet; Internal: Fiber Optical

Working Environment

 Temp. 23℃~29℃, Humidity: 50%~80%

Software

 FlexiPRINT / ONYX (Optional)......+GZ Printer Manager

Power

 Single Phase, 50Hz/AC, 220V±10%, 7A (Printer) + 2x12A (IR Dryer)

Packed / Installed Size

 LxWxH(mm):5400x1150x1760 / 5090x1375x1675

G.W. / N.W.

 1276KGS / 981KGS
