Print Head

8 x Epson I3200-A1 Print Heads

Ink

Gongzheng Specific Textile Pigment Ink

Color Config.

K.C.M.Y.+O.R.V.K.

Ink Supply System

1.5-Liter Bulk Ink Supply System with Ink Cartridges

Printing Width

Up to 1800mm

Media Type

Cotton, Blending Cotton, Polyester......

Feeder

Air Shafts and Tension Roller System

Roll Diameter

Up to 300 mm

Drying System

Intelligent Sectionable Control IR Dryer

Printing Speed

Mode                         Resolution                   8 Colors

Draft                        720x1200dpi                  81m²/h

Production              720x1200dpi                  45m²/h

High-Res                 720x2400dpi                  31m²/h

Photo                      720x2400dpi                   22m²/h

Data Interface

External: Ethernet; Internal: Fiber Optical

Working Environment

Temp: 20℃~25℃, Humidity: 40%-50%

Software

neoStampa Profiler+GZ Printer Manager

Power

Single Phase, 50Hz/AC, 220V±10%, 19.5A(Printer)+27A(IR Dryer)

Packed / Installed Size

LxWxH(mm): 3940x1420x1760 / 3760x1505x1635

G.W. / N.W.

1016KGS / 747KGS
